Pulse Eight neo:ULTRA HDMI Extender Set Uncompromised Video Extension

£x.xx

Manufacturer: Pulse Eight

Login to view price

Product Information

HDR and 4K/60 4:4:4 video content requires data rates exceeding 10 Gbps and up to 18 Gbps – a significant challenge for extending signals over HDBaseT. The P8UHD-KIT provides the answer with Display Stream Compression (DSC) a visually lossless video compression technology that applies extremely light line by line compression that causes no latency. This enables transmission of HDR and 4K/60 4:4:4 over a single category cable while ensuring very high, pristine image quality.

At just 13mm, our ultra thin HDBaseT transmitter and receivers are perfect for discrete mounting behind the latest displays and providing the most demanding clients with an ultra flat finish.



The ultimate HDBaseT™ extender solution. With built in DSC (Display Stream Compression) you can finally extend 4K/60 HDR10 over a HDBaseT link and upto 100m!

As standard the kit supports PoH (Power over HDBaseT), RS232, 10/100 Ethernet, Bi-Directional IR and Audio extension are included.



HDBaseT Class C technology enables a range of professional extension features, from RS232 to IR along with consumer functionality such as ARC and Optical Audio, the neo:Ultra Extender supports them all and with built-in IR diagnostics



IR Activity

With our new IR Activity sensor, IR flow appears Red or Green depending on the direction flow



Bi-Directional IR

Not just source control, sometimes your control system needs to use IR to control the TV or perhaps another item of equipment in the room, with bi-directional IR, you can connect P8-IRPACK RX or TX devices to control remote and local devices



RS232 / Serial

RS232 is still a popular way to control legacy equipment via 3.5mm or converted to a 9 Pin D-SUB



mini-TOSLINK / Analog Audio

Digital or Analog, whatever your preference we've got you covered. This port will accept a standard 3.5mm stereo jack and provide 2ch PCM audio, alternatively using a mini-TOSLINK adapter, connect a standard TOSLINK cable and get upto Dolby Digital 5.1 output.



HIGH DYNAMIC RANGE (HDR): 4K TV’S LATEST TECH AND WHAT IT MEANS FOR YOU

Bright, stunning, highlights and rich, vibrant colours, HDR is the most exciting new tech since 4K TVs first hit the market. New HDR-compatible televisions are just part of the story, though. The additional HDR data brings a whole new set of hardware challenges.

Learn all about HDR



Full Specification & Features

Dimensions (WxHxD): 14.8cm / 1.3cm / 10.5cm
Material: Aluminium
Room Operating Temperature Range: 0 to +35°C (32 to +95°F)
Room Operating Humidity Range: 20 to 90% RH (no condensation)
Power Supply: 1 x 48V @ 0.5A (TX only)
Power Consumption: Transmitter 7.3W, Receiver 8W
Video Input: Transmitter 1 X HDMI 2.0a, Receiver 1 X HDBaseT Class C (Ultra)
Video Output: Transmitter 1 X HDBaseT Class C (Ultra), Receiver 1 X HDMI 2.0a
Colour Depth: Up to 12bit
Max Video Bandwidth: 600MHz/18Gbps
Encryption: HDCP 1.4 and HDCP 2.2
Supported Video Resolutions: All 4K formats up to 4:4:4 @ 60Hz including 4:2:2 60Hz HDR 10, 720p, 1080i, 1080p (+3D)
Supported Audio Formats: PCM 2.0, LPCM 2.0, LPCM 5.1, LPCM 6.1, LPCM 7.1, Dolby Digital 2.0, Dolby Digital 5.1, Dolby Digital EX 6.1, Dolby Digital Plus 7.1, Dolby TrueHD 5.1, Dolby TrueHD 7.1, Dolby Atmos 5.1.2, Dolby Atmos 5.1.4, Dolby Atmos 7.1.2, Dolby Atmos 7.1.4, Dolby Atmos 9.1.2, DTS 5.1, DTS-HD Master 5.1, DTS-HD Master 7.1, DTS 96/24 5.1, DTS-ES Discrete 6.1, DTS-ES Matrix 6.1
ESD (Lightning) Protection: ± 8kV (Air-gap discharge) ± 4 kV (Contact discharge)
Certification: CE, FCC, RoHS







Product Code: P8UHD-KIT
