B-Tech BTV511 Ventry Flat Screen Wall Mount with Tilt

• Designed for screens up to 52” (132cm) / 50kg (110lbs)
• Suitable for VESA and Non-VESA mounting patterns
• Mounts screen only 44mm (1.73”) from wall
• 5 fixed tilt positions up to 15°
• Suitable for concrete, brick or stud walls up to 16”
• Post-installation screen alignment
• Includes locking bar for secure installation
• Simple 'hook-on' installation with all mounting hardware included

Specifications

• Screen Size: Up to 52”
• Max. Weight: 50kg (110lbs)
• Tilt: +15°
• Dist. From Wall: 44mm (1.73”)
• VESA Compatibility:
  50 x 50, 75 x 75, 100 x 100, 200 x 100, 200 x 200,
  300 x 200, 200 x 300, 300 x 300, 400 x 200, 400 x 300
• Max Distance between Fixings: H: 430mm (16.9”)  V: 300mm (11.8”)

Product Code: BTV511
