The CYP IP-CS9000 is a powerful centralised controller designed for the CYP IP-9000 Series 1G 4K60 AV over IP platform. It enables complete configuration, monitoring and control of multiple transmitters and receivers through an intuitive WebGUI, simplifying the management of large-scale AV over IP installations. Supporting both Unicast and Multicast routing, video wall control, USB over IP management and custom preset creation, the IP-CS9000 provides a flexible solution for corporate, education, hospitality, digital signage and control room environments. Dual LAN connectivity allows dedicated AV network operation while maintaining separate access for system control and configuration.

Features

• Centralised management for CYP IP-9000 Series AV over IP systems
• Automatic discovery and configuration of connected transmitters and receivers
• Supports Unicast and Multicast routing modes
• Intuitive WebGUI with drag-and-drop source switching
• Control and configuration of matrix and video wall layouts
• Create and manage custom groups, presets and macros
• USB over IP control for connected PC systems
• Dual LAN ports for separate AV and control networks
• Trigger input support for one-touch preset activation
• Control via WebGUI, RS-232, Telnet and IR Remote
• HDMI output for local system monitoring and configuration
• PoE support for simplified installation

Ideal For

Perfect for enterprise AV networks, meeting rooms, education facilities, hospitality environments, digital signage systems, control rooms and large-scale AV over IP deployments requiring centralised configuration, monitoring and control of multiple IP-9000 transmitters and receivers.

Specifications

• Product Type: AV Over IP System Controller & Configurator
• System Compatibility: CYP IP-9000 Series
• Network Ports: 2 × RJ45 LAN Ports
• HDMI Output: 1 × HDMI (Type-A)
• HDMI Output Resolution: 1920 × 1080p @ 60Hz
• USB Port: 1 × USB 2.0 Type-A (Data / Service)
• RS-232 Control Port: 1 × 3-Pin Phoenix Connector
• RS-232 Reserved Port: 1 × 5-Pin Phoenix Connector
• IR Port: 1 × 3.5mm IR Extender Port
• Trigger Input: 1 × 10-Pin Phoenix Connector (8 Trigger Inputs)
• Routing Modes: Unicast (Point-to-Point), Multicast (Multi-to-Multi)
• Control Methods: WebGUI, RS-232, Telnet, IR Remote
• Device Discovery: Automatic TX/RX Detection
• Video Wall Support: Yes
• Preset & Group Management: Supported
• USB Over IP Control: Supported
• PoE Support: IEEE 802.3af
• Power Supply: 5V DC / 2.6A (Locking)
• Power Consumption: 2.99W
• Dimensions (W × H × D): 231.5 × 25 × 108 mm
• Weight: 648g

Product Code: IP-CS9000
