The CYP OR-DT42-4K22 is a 4×2 HDMI matrix switcher with integrated Dante/AES67 network audio support, providing both HDMI matrix routing at up to 4K UHD+ (18Gbps) and the ability to insert and extract audio over a Dante network. Each HDMI output supports independent audio selection between the routed HDMI source or a Dante network audio source. Video resolutions up to 4K@60Hz 4:4:4 8-bit are supported for local routing, with 8-channel LPCM and HD Bitstream audio pass-through available via HDMI. Two-channel LPCM audio is supported via Dante. Per-output analogue audio extraction is provided via balanced or unbalanced Phoenix connectors. Dante audio management requires third-party software such as Dante Controller from Audinate. Control is available via front panel buttons, Web GUI, RS-232, and Telnet.

Ideal For

Well suited to control rooms, conference rooms, and classrooms requiring flexible 4K HDMI matrix switching combined with integration into an existing Dante or AES67 audio network for the transmission and reception of high-quality digital audio.

Features

• HDMI 2.0 and DVI 1.0 compliant (with the use of an HDMI-DVI adaptor)
• HDCP 1.x and 2.2 compliant
• 4 HDMI inputs and 2 HDMI outputs
• 4×2 matrix routing with per-output analogue audio extraction
• Supports video resolutions up to 4K UHD+ (18Gbps, 4K@50/60Hz 4:4:4, 8-bit)
• Supports pass-through of 8-channel LPCM, Bitstream, and HD Bitstream audio
• Each output's audio selectable between the routed HDMI source or an independent Dante network audio source
• Compatible with existing Dante and AES67 audio networks for uncompressed audio with near-zero latency
• Dante audio routing managed via third-party control software (Windows and macOS compatible)
• Per-input EDID management with internal or external EDID options
• Controllable via front panel buttons, Web GUI, Telnet, and RS-232

Specifications

• Inputs: 4 × HDMI (Uncompressed AV and Data), 1 × Phoenix 3-Pin (RS-232), 1 × RJ45 (Dante I/O), 1 × RJ45 (IP Control), 1 × USB Type-A (Service Port)
• Outputs: 2 × HDMI (Uncompressed AV and Data), 2 × Phoenix 5-Pin (Analogue Stereo, Balanced or Unbalanced)
• Power Supply: 5V / 2.6A
• Dimensions (W × H × D): 240 × 43 × 104 mm
• Net Weight: 800g
• Gross Weight: 1.32kg

Product Code: OR-DT42-4K22
